SJZ series vertical shaft drill

SJZ series vertical shaft drill SJZ series vertical shaft drill is a special equipment to drill blastholes for construction of vertical shaft. It has features of reliable, precise, easy to operate, and suits a wide range of shaft diameters. It is powered by pressed air, transmitted by hydraulic system, and all the movements of drill mounting are machine motivated. While using highly effective pneumatic drifter, long propelling stroke, and parallel movement mechanism, the accuracy of drilling blasthole and its efficiency are naturally upgraded, thus auxiliary working time is greatly saved. Specification of SJZ series vertical shaft drill Technical itemsUnitSJZ5.5SJZ5.6SJZ6.7SJZ6.9SJZ6.10Number of supporting boom Pcs.33333Number of moving boom Pcs.55666Fixing range of supporting boom mø4.6-6.6ø5.7-7.7ø4.6-6.7 ø5.7-7.7 ø6.6-8.6ø6.6-9.8ø7.6-10.8Vertical blasthole coverage mø1.6-6.3ø1.65-8.2ø1.65-8.2ø1.65-9.56ø1.65-10.5Air pressure MPa0.5-0.70.5-0.70.5-0.70.5-0.70.5-0.7Max. air consumption M3/min5858686868Retracted dimension dia. × height mø1.7x6ø1.9x7.2ø1.9x7.2ø1.9x7.7ø1.9x8.2Shank mmB25 159hex steel rodB25 159hex steel rodB25 159hex steel rodB25 159hex steel rodB25 159hex steel rodBit dia. mmø38ø55ø38ø55ø38ø55ø38ø55ø38ø55Length of steel rod m3.94.74.74.74.7Total weight kg53006300780082009000
